stainless steel 347 347H tubes pipes EN 10216-5 1.4550 Stainless Steel Tubing piping

stainless steel 347 347H tubes pipes EN 10216-5 1.4550 Stainless Steel Tubing piping

Key words

347 347H pipes, 347 347H tubes,347 347H piping,347 347H tubing,Stainless steel 347 347H pipes ,stainless steel 347 347H piping, stainless steel 347 347H tubes ,stainless steel 347 347H tubing,stainless steel 347 347H tubes pipes,stainless steel 347 347H tubing piping,Stainless steel seamless 347 347H tubes pipes,EN 10216-5 1.4541 tubes pipes,ASTM A213 347 347H tubes pipes,347 347H industrial tubes pipes,347 347H precision tubes pipes,347 347H bright annealing tubes pipes,347 347H capillary,ASTM A632 standard 347 347H capillary tubing, ASTM A213 A312 A269 standard stainless steel 347 347H tubes tubing ,ASME SA 213 / ASTM A213 A269 347 347H Stainless Steel Pipe piping,

Introduce：

ASTM A213 ASME SA 213 347 347H EN 10216-5 1.4550 is a stabilized stainless steel which offers as its main advantage an excellent resistance to intergranular corrosion following exposure to temperature in the chromium carbide precipitation range from 800 to 1500°F (427 to 816°C). Alloy 347 347H is austenitic chromium steel containing columbium stabilized by the addition of columbium and tantalum.
Alloy 347 stainless steel is also advantageous for high temperature service because of its good mechanical properties. Alloy 347 stainless steel tubing offers higher creep and stress rupture properties than Alloy 304 and, particularly, Alloy 304L, which might also be considered for exposures where sensitization and intergranular corrosion are concerns. 347 stainless steel has a high resistance to prolonged heat and corrosion making it well suited for engine, power generation, welded fabrications and other high heat applications. 347 stainless steel offers good mechanical properties with higher creep and stress rupture characteristics than other grades, such as 304. 347 stainless steel is also advantageous in applications that require omission of the annealing process after welding.
347 stainless steel Similar to 321 stainless, 347 uses columbium as a stabilizing element to maximize its principal feature: resistance to intergranular corrosion. It can be used in applications requiring repeated heating in the range of 800 and 1650 F (427-899 C).
Applications for 347 347H stainless steel include those for welded construction and parts subjected to heating in the carbide precipitation range, aircraft collector rings, aircraft exhaust stacks, boiler casings, cabin heaters, Stainless Steel Reheater Tubes and Superheater Tubes for Boiler, carburetor air intensifier tubes, exhaust manifolds, fasteners, fire walls, flash boilers, flexible couplings, furnace heating elements, jet engine parts, large mufflers for stationary diesel engines, pressure vessel, stack liners, all-welded tank car for carrying chemicals, annealing box inner covers, collector rings, expansion joints, heat resistors, heavy wall welded equipment, welded tanks for storing organic chemicals, wire cloth and screens (industrial).

General Properties
Chemical Composition
Resistance to Corrosion
Physical Properties
Mechanical Properties
Elevated Temperature Oxidation Resistance
Heat Treatment
Fabrication

Table1.Mechanical Properties of stainless steel 347 347H tubes pipes in the Annealed Condition at -20°F to +100°F

Table2.Chemical Composition of ASTM A213 stainless steel 347 347H tubes pipes

Table3.stainless steel 347 347H tubes pipes Product Range

347 347H Stainless Steel Density Specific Gravity: 7.98 (kg/m3)

347/347H Stainless Steel Specifications
ASTM A312, A403, A182, A479, A276
ASME SA312, SA403, SA182, SA479, SA276

stainless steel 347 347H tubes pipes Stainless Steel Description
These types of stainless are austenitic chromium steels containing columbium. They are recommended for parts fabricated by welding which cannot be subsequently annealed. These types also are used for parts which are intermittently heated and cooled to temperatures between 800 deg. and 1600 deg.F. The addition of columbium produces a stabilized type of stainless that eliminates carbide precipitation, and consequently, intergranular corrosion.

stainless steel 347 347H tubes pipes Design Features

• Superior general corrosion resistance over Type 321 due to stabilization with columbium.

• Reduced tendencies to form continuous networks of chromium carbides at the grain boundaries.

• Better high temperature properties than 304 or 304L. Generally used for parts which are intermittently heated up to 1500 deg. F. For continuous service the maximum temperature is 1650 deg. F.

• Type 347H has high carbon (.04 - . 10) for better high temperature creep properties.

• Improved intergranular corrosion resistance.

Benefits of stainless steel 347 347H tubes pipes

Higher creep stress and rupture properties when compared with 304

Ideal for high temperature service

Overcomes sensitization and intergranular corrosion concerns

Can be used in elevated temperature applications for ASME Boiler and Pressure Vessel Code applications

Due to stabilisation the material offers better overall corrosion resistance when compared to 304/304L

Excellent mechanical properties

A high carbon version (347H) is also available

347/347H Stainless Steel be used more Corrosion Resistance

347/347H Stainless Steel be used more Tensile Requirements

stainless steel 347 347H tubes pipes Typical Applications

High temperature chemical process, Heat exchanger tubes

Refineries

High temperature steam service

Stainless Steel Reheater Tubes and Superheater Tubes for Boiler

Heat exchangers

High temperature steam service

High temperature chemical process

stainless steel 347 347H tubes pipes Corrosion Resistance

The following table is for reference only, many factors can affect the corrosive resistance, a corrosion test for each application should be applied.

stainless steel 347 347H tubes pipes Heat Treatment

Annealing:

Heat to 1850/2000 F (1010/1093c) and quench in water. Brinell hardness approximately 150.

Hardening:

Cannot be hardened by heat treatment, it can only be hardened through cold working.

Stabilizing:

If temperature during use is expected up to 1600 degrees, stabilizing between 1550/1650f (843/899c) can be used for optimum intergranular corrosion.

347/347H Stainless Steel Machinability:

When machining 347 its chip is tough and stringy, use rigid tooling with heavy cuts to prevent work hardening.

Specifications:

AMS 5646 ASTM A182 ASTM A213 ASTM A269 ASTM A276 ASTM A312 ASTM A314 ASTM A473 QQS 763 ASME SA182 EN10204 DIN3.1B
