Nickel Alloy N08811 Incoloy800HT Seamless Tubes Pipes Incoloy800H EN 10216-5 1.4959 Tubing piping

Nickel Alloy N08811 Incoloy800HT Seamless Tubes Pipes Incoloy800H EN 10216-5 1.4959 Seamless Tubing piping

Key words

Nickel Alloy N08811 Incoloy800HT pipes tubes,Nickel Alloy N08811 Incoloy800HT tubing piping, Stainless steel Nickel Alloy N08811 Incoloy800HT pipes tubes,stainless steel Nickel Alloy N08811 Incoloy800HT tubing piping,Nickel Alloy N08811 Incoloy800HT seamless tubes pipes,Nickel Alloy N08811 Incoloy800HT seamless tubing piping,Nickel Alloy N08811 Incoloy800HT industrial tubes pipes,Nickel Alloy N08811 Incoloy800HT precision tubes pipes,Nickel Alloy N08811 Incoloy800HT bright annealing tubes pipes,Nickel Alloy N08811 Incoloy800HT capillary, ASTM A632 Nickel Alloy N08811 Incoloy800HT capillary tubing, ASTM B163 B407 Nickel Alloy N08811 Incoloy800HT tubes pipes,TINSI-STELL Nickel Alloy EN 10216-5 1.4959 tubes pipes，TINSI-STELL Nickel Alloy EN 10216-5 1.4959 tubing piping,TINSI-STELL stainless steel Nickel Alloy EN 10216-5 1.4959 seamless tube pipes,stainless steel Nickel Alloy EN 10216-5 1.4959 seamless tubing pipeing,ASTM B163 B407 ASME SB163 SB407 N08811 Nickel Alloy Seamless Tubes Pipes Incoloy 800HT EN 10216-5 1.4959  Seamless Tubing piping

Type of Material Grade:

UNS: N08811

EN Number: 1.4959/1.4876

EN Name: X8NiCrAlTi32-21

W.Nr.: 1.4959 /1.4876

DIN: X 10 NiCrAlTi 32 20 /X 5 NiCrAlTi 31 20 /X 10 NiCrAlTi 32 20 H

Alloy 800HT

Characteristic Of ASTM B163 B407,ASME SB163 SB407,UNS N08811 EN 10216-5 1.4959 Nickel Alloy Seamless Tube Pipe Incoloy 800HT Seamless Tubing  is an austenitic nickel-iron-chromium alloy as below:

·  Excellent corrosion resistance in the water media of the extremely high temperature of 500℃.

·  Good stress corrosion resistance

·  Good machining

·  High creep strength

·  Very good resistance to oxidation

·  Good resistance to combustion gases

·  Very good resistance to carburization

·  Good resistance to nitrogen absorption

·  Good structural stability at high temperatures

·  Good weldability
ASTM B163 B407 ASME SB163 SB407 N08811 Nickel Alloy Seamless Tubes Pipes Incoloy 800HT Seamless Tubing can be used at temperatures up to about 1100°C (2010°F). In order to have the best ductility, it should be used above 700°C (1290°F).
800H is face-centered cubic lattice structure. very low carbon centent and increased Ti:C rate,improve the stability of the structure, anti-allergy , and anti-intergranular corrosion. Low temperature annealing of 950℃ ensure the fine grain structure.

TINSI Stainless Steel Co., Ltd is one of the leaders manufacturer & stockist & exporters in stainless steel Pipes &Tubes.our team professional more than 20 years focus on manufacturing stainless steel tubes&pipes and Duplex steel tubes&pipes and Nickel alloy steel tubes&pipes in industrial pipes, precision pipes, sanitary pipes, capillary and needle pipe.

Our company and warehouse in Wenzhou，factory of industrial pipes moved to Songyang,in the stainless steel pipes&tubes that production and sell all control by self,Advanced technology and excellent quality with more than 1200 tons ready stock of industry pipes,offer best price with best services has made TINSI company a true performer in the market domestic.

Corrosion Resistance Of ASTM B163 B407 ASME SB163 SB407 N08811 Nickel Alloy Seamless Tubes Pipes Incoloy 800HT Seamless Tubing:
800H can not be corroded in many kinds of media. Its high nickel content made it have good stress corrosion resistance cracking properties in the water corrosion condition.High Chromium content made it can better resist pitting and crevice corrosion cracking. This alloy can resist nitric acid and organic acid corrosion, but it is not so fine in the sulfuric acid and hydrochloric acid.
UNS N08811 not only good corrosion resistance in both oxidation resistance and non-oxidizing salt, maybe a little pitting in halide, but also very good corrosion resistance property in the mixture of water,smoke, steam,air and carbon dioxide.

Specification ASTM B163 B407 ASME SB163 SB407 N08810 Nickel Alloy Seamless Tubes Pipes Incoloy 800H Seamless Tubing 1.4958:
Seamless condenser and heat exchanger tubes: ASTM A213, ASTM B163, EN 10216-5

Seamless tube and pipe: ASTM A312, ASTM B407, EN 10216-5

ASME SB163 Standard Specification for Seamless Nickel and Nickel Alloy Condenser and Heat-Exchanger Tubes

ASME SB165 Standard Specification for Nickel-Copper Alloy (UNS N04400)* Seamless Pipe and Tube

ASME SB167 Standard Specification for Nickel-Chromium-Iron Alloys, Nickel-Chromium-Cobalt-Molybdenum Alloy (UNS N06617),and Nickel-Iron-Chromium-Tungsten Alloy (UNS N06674) Seamless Pipe and Tube

ASME SB407 Standard Specification for Nickel-Iron-Chromium Alloy Seamless Pipe and Tube

ASME SB423 Standard Specification for Nickel-Iron-Chromium-Molybdenum-Copper Alloy (UNS N08825, N08221, and N06845) Seamless Pipe and Tube

ASME SB444 Standard Specification for Nickel-Chromium-Molybdenum-Columbium Alloys (UNS N06625 and UNS N06852) and Nickel-Chromium-Molybdenum-Silicon Alloy (UNS N06219) Pipe and Tube

ASME SB622 Standard Specification for Seamless Nickel and Nickel-Cobalt Alloy Pipe and Tube

ASME SB668 UNS N08028 Seamless Pipe and Tube

ASME SB690 Standard Specification for Iron-Nickel-Chromium-Molybdenum Alloys (UNS N08366 and UNS N08367) Seamless Pipe and Tube

ASME SB729 Standard Specification for seamless UNS N08020, UNS N08026, and UNS N08024 nickel alloy seamless pipe and Tube

EN 10216-5 Seamless steel tubes for pressure purposes

Chemical composition Of ASTM B163 B407 ASME SB163 SB407 N08811 Nickel Alloy Seamless Tubes Pipes Incoloy 800HT Seamless Tubing piping:

N08811 Nickel Alloy Seamless Tubes Pipes Incoloy 800HT Physical properties:7.94 g/cm³

N08811 Nickel Alloy Seamless Tubes Pipes Incoloy 800HT Melting points:1350-1400 ℃

minimum mechanical properties in the room temperature Of ASTM B163 B407 ASME SB163 SB407 N08811 Nickel Alloy Seamless Tubes Pipes Incoloy 800HT Seamless Tubing piping

Typical Application range and field ASTM B163 B407 ASME SB163 SB407 N08811 Nickel Alloy Seamless Tubes Pipes Incoloy 800HT Seamless Tubing piping:
1.Nitrate condenser---Corrosion resistance of Nitric acid
2.Steam heating pipes--Very good mechanical properties
3.Heat up element tube--Very good mechanical properties
4. Stainless Steel Reheater Tubes and Superheater Tubes for Boiler with corrosive conditions. For the application of up to 500℃ environment, alloy state supplies change to annealing.

At TINSI-STEEL Stainless Tubes, quality management begins way ahead of any production step.

From the selection of raw material suppliers up to the final quality tests in our own factory we thoroughly evaluate, test and control our products and processes, aiming at continuous improvements. For in process and acceptance inspection, the quality departments at the individual manufacturing centers have state of-the-art equipment at their disposal including mechanical workshops, tensile and impact testing machines, chemical laboratories for corrosion tests, equipment for hardness testing and metallographic inspection.We also have extensive facilities for non-destructive testing, including ultrasonic, eddy current, hydrostatic, positive mate- rial identification and dye penetrant testing.

If your company needs tubing, you can rely on TINSI company. Thanks to our precision engineered manufacturing procedures, we easily and effectively respond to our customers' requirements, no matter how stringent they may be. Innovations in processes allow us to continually expand the range of product solutions. TINSI-STEEL engineers closely follow each phase of production and testing to ensure nickel alloy seamless tubes pipes of superior performance.
