stainless steel precision tube&pipe

  • precision tubes pipes Bright annealed seamless Precision rolling Precision draw tubing piping
  • precision tubes pipes Bright annealed seamless Precision rolling Precision draw tubing piping
  • precision tubes pipes Bright annealed seamless Precision rolling Precision draw tubing piping
  • precision tubes pipes Bright annealed seamless Precision rolling Precision draw tubing piping
precision tubes pipes Bright annealed seamless Precision rolling Precision draw tubing pipingprecision tubes pipes Bright annealed seamless Precision rolling Precision draw tubing pipingprecision tubes pipes Bright annealed seamless Precision rolling Precision draw tubing pipingprecision tubes pipes Bright annealed seamless Precision rolling Precision draw tubing piping

precision tubes pipes Bright annealed seamless Precision rolling Precision draw tubing piping

  • OD:6-140mm THK:0.9-25mm
  • SUFACE:AP(Annealed and pickling) / MP(mechanically polish)MB (finish rolling bright)or BA ( bright annealing) or MP (MB+polish)
  • Product description: precision tubes pipes Bright annealed seamless Precision rolling Precision draw tubing piping,Stainless steel precision tubes pipes,stainless steel precision tubing piping,stainless steel seamless pre
  • INQUIRY

precision tubes pipes Bright annealed seamless Precision rolling Precision draw tubing piping

Key word

Stainless steel precision tubes pipes,stainless steel precision tubing piping,stainless steel seamless precision tubes pipes,stainless steel welded precision tubes pipes,austenitic stainless steel seamless precision tubes pipes,duplex steel precision tubes pipes,alloy precision tubes pipes ,Precision rolling tubes pipes tubing,precision drawn tubes pipes tubing,Bright annealed tubes pipes tubing

Type of key word about precision tubes pipes

Bright annealed tubes pipes tubing

BA tubes BA pipes BA tubing

instrumentation tubes pipes tubing

Hydraulic tubes Pipes tubing

Mechanical tubes pipes tubing

Polish tubes pipes tubing


Stainless steel precision pipe, as the name implies with very precise tolerance of internal and external diameter and wall thicknessand more characterized by ovality, eccentricity and controlled hardness required for superior performance of precision systems.

TINSI is a Professional manufacturer of stainless steel precision tubes, which is being made up from High Quality of Standard Raw Materials. Owing to the expertise and proficient team of diligent personnel, we are offering a wide and comprehensive range of these tubes. We have a pride in presenting a comprehensive collection of innovative, high-class and customizable Precision Bright Annealed Stainless Steel Tubes by using state-of-art technology. We offer this tubes&pipes in different grades, thickness, size and specification according to requirements of our customers, Aiming to satisfy our clients, we are engaged in offering a high quality Stainless Steel precision Bright Annealing polish sanitary Seamless Pipes.


TINSI is a Professional manufacturer of stainless steel precision Bright Annealed Tubes, which is being made up from High Quality of Standard Raw Materials. Owing to the expertise and proficient team of diligent personnel, we are offering a wide and comprehensive range of these tubes. We have a pride in presenting a comprehensive collection of innovative, high-class and customizable Precision Bright Annealed Stainless Steel Tubes by using state-of-art technology. We offer this tubes&pipes in different grades, thickness, size and specification according to requirements of our customers, Aiming to satisfy our clients, we are engaged in offering a high quality Stainless Steel precision Bright Annealing polish sanitary Seamless Pipes.


Advantage of precision tubes&pipes of TINSI-STEEL

1.More precise dimension

TINSI steel using the high quality industrial raw materials pipe produced by ourselves and advanced three-roller-precision-cold-rolling technology, making the close dimension controls. for higher precision requirements tubes&pipes tinsi-steel could using precision rolling or precision draw processing repeated times so that finish minimum tolerance more better than specification  standard.

2. Better mechanical property

Using bright annealing method, the temperature of furnace can reach more than 1350℃, and the tolerance for the setting and real temperature can be controlled within +/-10℃, which is impossible for the traditional annealing.

3. Superior surface finish

The traditional annealing method is performed in a so called open furnace, where the atmospheric oxygen causes scaling of the heat treated materials, which makes the surface rough. We tinsi steel usually uses bright annealing process to produce stainless steel precision tubes,the heat treatment is performed in a so called closed furnace. The heat treated materials is protected by an inter gas atmosphere, which guarantees the oxygen cannot enter the furnace or come in to contact with the materials and react to form scale on or tarnish the materials. The surface finish is clean, bright and precision, which is an excellent starting point for further process, like electro-polishing and mechanical polishing.

4. Perfect inspection method and inspection equipment

TINSI more dimension test and strict quality control  in production,and ensure the quality to meet various requirements of each tube, we also more strict test such as PMI test, Hydraulic, inner cleaned by sponge, dimension test, and surface test. What’s more, TINSI offer precision drawn tubing that the quality is similar to precision rolling, but has more advantage on price.

5. Tinsi using bright annealing especially for the precision tubes pipes with length more than 12 meters, the traditional pickling tube is very hard to clean the inner surface, however, with the bright annealing method, the tubing is much cleaner, smoother on both inner and outer surfaces.And tinsi-steel also used for small diameter capillary and needle tube to ensure the inner hole is clean


Introduce of tinsi-steel precision

stainless steel sanitary or precision tubes&pipes

Description

stainless steel sanitary or precision tubes&pipes: outer diameter 8-114mm, wall thickness 0.5-4mm.Main standards:ASTM A270/ASTM A632/ASTM A511/etc.Precision pipes are processed again by precision cold rolling or drawing with seamless or welded industrial tubes as mother tube.it more precise tolerance and high quality by precise process make inner and outer finish surface smooth that maximum tolerance size accuracy ±≤0.02-0.05mm. inner wall roughness Ra < 0.7 um and after polishing Ra < 0.4-0.25 um.Mainly used hardware equipment of automation, medical, beer, precision instrumentation,etc.Usually BA ( bright annealing after rolling surface) or MB (finish rolling bright surface) or MP (MB+polishing)

Process Method

Seamless cold precision drawn&cold precision rolling

Standard

ASTM A270,ASTM A 269,ASTM A632,ASTM A511,EN10216-5ISO1127,etc

Material Grade

Mainly:TP304,TP316L

Outer Diameter

8mm-114mm

Thickness

0.8mm-4mm

Length

5-7Mtr of ready stock or as customers' request. Max about 10Mtr

Tolerance

OD/ID :±0.05--±0.15mm ; THK :±0.05--±0.15mm; within standard

Surface

MB (finish rolling bright)or BA ( bright annealing) or MP (MB+polish)

Test

Dimension Examination,PMI,Roughness,UT, ET, HT, RT,etc,

Application

Automation equipment, Hydraulic system,Medical,Precision instrument and parts, Electric heat pipe, Automobile,etc


Type of key word about precision tubes pipes

precision tubes pipes tubing

Precision rolling tubes pipes tubing

precision drawn tubes pipes tubing

Bright annealed tubes pipes tubing

BA tubes BA pipes BA tubing

instrumentation tubes pipes tubing

Hydraulic tubes Pipes tubing

Mechanical tubes pipes tubing

Polish tubes pipes tubing

Sanitary tubes pipes tubing

Surface grade
